InVision HD Digital Dash Kit for 1968 Chevy Chevelle

The AutoMeter InVision HD digital dash display is a complete dashboard system for the 1968 Chevy Chevelle. It includes a 12.3″ high-definition color LCD that shows all the essential gauges, such as the speedometer, tachometer, oil pressure, water temperature, fuel level, and voltmeter. The package includes a pre-terminated, color-coded universal wiring harness, sensors, adapters, and a panel-mounted joystick for programming.

Specifications

Brand AutoMeter Part Number 7401 Product Line Invision HD Application Specific Yes Programmable Yes Screen Size Diagonal 12.3 in Clock Yes Fuel Level Gauge Yes Fuel Level Gauge Warning Light Yes Oil Pressure Gauge Included Yes Oil Pressure Gauge Warning Light Yes Oil Pressure Warning Light Color Red Oil Pressure Gauge Sending Unit Yes Oil Pressure Gauge Sending Unit Thread Size 1/8 in NPT Oil Pressure Gauge Sending Unit Thread Style Male Oil Pressure Minimum 0 PSI Oil Pressure Maximum 100 PSI Water Temperature Gauge Included Yes Water Temperature Gauge Warning Light Yes Water Temperature Warning Light Color Red Water Temperature Gauge Sending Unit Yes Water Temperature Gauge Sending Unit Thread Size 1/8 in NPT Water Temperature Gauge Sending Unit Thread Style Male Water Temp Minimum Degrees Fahrenheit 100 Degrees Water Temp Maximum Degrees Fahrenheit 260 Degrees Volt Meter Included Yes Voltage Minimum 8 Volts Voltage Maximum 16 Volts Tachometer Included Yes Minimum RPM 0 RPM Maximum RPM 10000 RPM Speedometer Included Yes Minimum MPH 0 MPH Maximum MPH 160 MPH Odometer Yes Trip Meter Yes Fittings Included Yes Fitting A Quantity 1 Fitting A End 1 Size 3/8 in NPT Fitting A End 1 Style Male Fitting A End 2 Size 1/8 in NPT Fitting A End 2 Style Female Fitting B Quantity 1 Fitting B End 1 Size 1/2 in NPT Fitting B End 1 Style Male Fitting B End 2 Size 1/8 in NPT Fitting B End 2 Style Female Fitting Material Brass Fitting Color Natural Fitting Finish Natural Mount Included Yes Hardware Included Yes Light Color Blue | Green Quantity Kit
